SMC VZS22505FZ (VZS2250-5FZ) - 5 Port Pilot Operated Solenoid Valve, Metal Seal, Plug-in, 24 VDC Coil, Plug-in Type
SMC VZS22505FZ 5 Port Pilot Operated Solenoid Valve, Metal Seal, Plug-in — 2 position double solenoid without CE suffix. 5 port pilot operated solenoid valve, metal seal, plug-in, 2 position double, 24 VDC, light/surge voltage suppressor, non-locking push manual override, without sub-plate.
MPN: VZS2250-5FZ · SKU: VZS22505FZ
VZS2250-5FZ Applications
The SMC VZS22505FZ is the 2 position double solenoid build and carries no CE suffix, so it latches in its last commanded position when power is removed rather than spring returning. It is used on manifold valve banks in general factory automation, assembly cells and material handling. It suits memory-function circuits, double-acting cylinder control and applications that must hold position through a power interruption. The metal seal main valve gives long life and fast response, and the plug-in entry keeps manifold wiring tidy. SMC discontinued this series in April 2023; the replacement is the SY3000 series.
VZS2250-5FZ Specifications
| Brand | SMC | Manufacturer Part No. | VZS2250-5FZ |
| Product Type | 5 Port Pilot Operated Solenoid Valve, Metal Seal, Plug-in | Series | VZS2000 |
| Type Of Actuation | 2 - 2 Position Double | Coil Rated Voltage | 5 - DC24V |
| Electrical Entry | F - Plug-in Type | Light/Surge Voltage Suppressor | Z - With Light/Surge Voltage Suppressor |
| Pilot Valve Manual Override | Non-locking Push Type (Flush) | Bore Size | Without Sub-plate |
| Thread Type | Rc or Without Sub-plate | CE-compliant | Not specified |
| Main Valve Construction | Metal seal | Manifold Type No. | VV5ZS2 / VV5ZS3 |
| Lifecycle | Manufacture discontinued 4/2023; replacement series SY3000 |
