SMC VQZ3125YO102FQ (VQZ312-5YO1-02F-Q) - 3 Port Solenoid Valve, Rc1/4 Port, Metal Seal N.C.
SMC VQZ3125YO102FQ 3 Port Solenoid Valve — metal seal N.C. with Rc1/4 G-thread port. VQZ300 series 3 port solenoid valve, body ported single unit, 18 mm body width, metal seal N.C., 24 VDC, DIN terminal without connector, Rc1/4 2(A) port, G thread, CE-compliant.
MPN: VQZ312-5YO1-02F-Q · SKU: VQZ3125YO102FQ
VQZ312-5YO1-02F-Q Applications
The SMC VQZ3125YO102FQ is the metal seal normally-closed build with an Rc1/4 G-thread port, which separates it from the normally-open VQZ3425YZ1C8 in the same VQZ300 frame. It is used in 3 port air control on packaging, textile and general assembly machinery. It is suited for single-acting cylinder driving, blow-off and purge circuits, and pilot supply to larger valves. The metal seal construction gives long life in high-cycle duty, and the DIN terminal without connector lets the installer fit their preferred cable gland.
VQZ312-5YO1-02F-Q Specifications
| Brand | SMC | Manufacturer Part No. | VQZ312-5YO1-02F-Q |
| Product Type | 3 Port Solenoid Valve, Body Ported Single Unit | Series | VQZ300, Body Width 18 mm (3) |
| Mounting | Body Ported | Type Of Actuation | Metal Seal N.C. (1) |
| Function | Standard | Coil Voltage | 24 VDC (5) |
| Electrical Entry | DIN Terminal Without Connector (YO) | Manual Override | Non-locking Push Type (Tool Required) |
| Port Size 2(A) Port | Rc1/4 (02) | Thread Type | G (F) |
| Option | None | CE-compliant | CE-compliant (Q) |
