SMC VQC2100KN5B1 (VQC2100KN-5B1) - 5 Port Solenoid Valve, 1.0 MPa High Pressure, Negative Common
SMC VQC2100KN5B1 5 Port Solenoid Valve — KN high pressure 1.0 MPa negative common with locking override. VQC2000 series 5 port solenoid valve, base mounted plug-in unit, 2 position single, metal seal, high pressure 1.0 MPa 0.95 W with negative common, 24 VDC, locking manual override, IP67.
MPN: VQC2100KN-5B1 · SKU: VQC2100KN5B1
VQC2100KN-5B1 Applications
The SMC VQC2100KN5B1 combines the KN high pressure 1.0 MPa coil with negative common wiring, setting it apart from standard-pressure positive-common VQC2000 siblings. It is used in elevated-pressure air circuits on press tooling, clamping fixtures and heavy assembly automation. It is suited for sinking-output PLC cards, high-force actuator driving, and manifold valve banks needing a locking override for commissioning. Its metal seal construction supports high-cycle duty and long service life at 1.0 MPa.
VQC2100KN-5B1 Specifications
| Brand | SMC | Manufacturer Part No. | VQC2100KN-5B1 |
| Product Type | 5 Port Solenoid Valve, Base Mounted Plug-in Unit | Series | VQC2000 |
| Type Of Actuation | 2 Position Single (1) | Seal | Metal Seal (0) |
| Function | High Pressure Type 1.0 MPa, 0.95 W + Negative Common (KN) | Coil Voltage | 24 VDC (5) |
| Light/Surge Voltage Suppressor | Yes | Manual Override | Locking Type, Tool Required (B) |
| Enclosure | IP67 Compliant |
