SMC VP4250045D (VP4250-045D) - Large Size 5 Port Solenoid Valve, 2 Position Double Solenoid, Rc1/2 Port
SMC VP4250045D Large Size 5 Port Solenoid Valve — 2 position double solenoid actuation that latches its last position on power loss. rubber seal, large size 5 port solenoid valve, 2 position double, 3/4 standard body, side ported, Rc1/2 port, 24 VDC, DIN terminal.
MPN: VP4250-045D · SKU: VP4250045D
VP4250-045D Applications
The SMC VP4250045D is used to drive large bore cylinders that must hold their last commanded position if control power is lost. It is suited to heavy clamping, large gate and damper actuation, and press circuits where an unexpected spring return would be unsafe. The 2 position double solenoid construction latches the spool after a momentary pulse on either coil, reducing coil heating on long dwell cycles and letting the PLC drive the valve with short signals rather than a continuously energised output.
VP4250-045D Specifications
| Brand | SMC | Manufacturer Part No. | VP4250-045D |
| Product Type | Large Size 5 Port Solenoid Valve | Series | VP4x50/4x70 |
| SMC Series Description | VP4-50/4-70 Series, Rubber Seal, Large Size 5 Port Solenoid Valve | Type Of Actuation | 2 - 2 Position Double |
| Body Size | 5 - 3/4 Standard | Piping | 0 - Side Ported |
| Port Size | 04 - 1/2 (15A) | Rated Voltage | 5 - 24 VDC |
| Electrical Entry | D - DIN Terminal | Thread Type | Rc |
| Made To Order | Standard |
