SMC VP4150045D (VP4150-045D) - Large Size 5 Port Solenoid Valve, 2 Position Single Solenoid, Rc1/2 Port
SMC VP4150045D Large Size 5 Port Solenoid Valve — 2 position single solenoid actuation on a side ported Rc1/2 body. rubber seal, large size 5 port solenoid valve, 2 position single, 3/4 standard body, side ported, Rc1/2 port, 24 VDC, DIN terminal.
MPN: VP4150-045D · SKU: VP4150045D
VP4150-045D Applications
The SMC VP4150045D is used to drive large bore pneumatic cylinders that need high flow. It is suited to heavy clamping circuits, large press and gate actuation, and bulk material handling equipment where a small valve would starve the cylinder. The 2 position single solenoid action returns the spool by spring when the coil is de-energised, giving a defined fail position on power loss, and the DIN terminal entry allows quick field wiring and disconnection during maintenance.
VP4150-045D Specifications
| Brand | SMC | Manufacturer Part No. | VP4150-045D |
| Product Type | Large Size 5 Port Solenoid Valve | Series | VP4x50/4x70 |
| SMC Series Description | VP4-50/4-70 Series, Rubber Seal, Large Size 5 Port Solenoid Valve | Type Of Actuation | 1 - 2 Position Single |
| Body Size | 5 - 3/4 Standard | Piping | 0 - Side Ported |
| Port Size | 04 - 1/2 (15A) | Rated Voltage | 5 - 24 VDC |
| Electrical Entry | D - DIN Terminal | Thread Type | Rc |
| Made To Order | Standard |
