SMC VP3165105DZA (VP3165-105DZA) - Large Size 3 Port Solenoid Valve, Rc1 Port, N.C. Actuation
SMC VP3165105DZA Large Size 3 Port Solenoid Valve — Rc1 ported N.C. valve with DIN terminal and light/surge voltage suppressor. rubber seal, large size 3 port solenoid valve, body ported single solenoid, body size 1, Rc1 port, 24 VDC, DIN terminal with light and surge voltage suppressor, N.C., internal pilot.
MPN: VP3165-105DZA · SKU: VP3165105DZA
VP3165-105DZA Applications
The SMC VP3165105DZA is used where a very high flow 3 port solenoid valve is needed for supply or exhaust duty. It is suited to large air reservoir charging, blow-off and air knife circuits, and main air supply switching on heavy plant. The large flow capacity and small exhaust resistance let the valve fill and dump big volumes quickly, while the DIN terminal with integral light and surge voltage suppressor protects the driving output and confirms the coil state at a glance.
VP3165-105DZA Specifications
| Brand | SMC | Manufacturer Part No. | VP3165-105DZA |
| Product Type | Large Size 3 Port Solenoid Valve | Series | VP3145/3165/3185 |
| SMC Series Description | VP3145-3165-3185 Series, Rubber Seal, Large Size 3 Port, Solenoid Valve, Body Ported/Single Solenoid | Body Size | 6 - 1 |
| Valve Option | For General | Port Size | 10 - 1 |
| Coil Rated Voltage | 5 - 24 VDC | Electrical Entry | DZ - DIN Terminal With Light/Surge Voltage Suppressor |
| Type Of Actuation | A - N.C. | Pilot Type | Internal Pilot |
| Thread Type | Rc | CE-compliant | - |
