SMC VHS50N06AZ (VHS50-N06-A-Z) - Lockable Shut-Off Valve, NPT3/4 Port

SMC VHS50N06AZ Lockable Shut-Off Valve — NPT3/4 port, size 50, PBT handle, psi label. 3-port manual residual-pressure-release (lockable shut-off) valve. Body size 50, NPT3/4 (N06) port, flame-resistant PBT handle/bonnet (A) and psi-unit label (Z). Single action, red handle on white aluminium die-cast (ADC12) body. Fluid: air. Operating pressure 0.1 to 1.0 MPa, proof pressure 1.5 MPa. Ambient/fluid temperature -5 to 60 C (no freezing). 90-degree switching, rotating torque 3.5 N-m or less. Padlockable in exhaust position for energy isolation (LOTO), OSHA compliant.

MPN: VHS50-N06-A-Z · SKU: VHS50N06AZ

VHS50-N06-A-Z Applications

Isolates supply air and exhausts downstream residual pressure before maintenance on the largest size-50 pneumatic lines with NPT3/4 (N06) porting for high-flow North American systems. Supplied with a flame-resistant PBT handle/bonnet (A) and a psi-unit label (Z) for US installations. The red handle padlocks in the OFF/exhaust position as a lockout-tagout energy-isolation point.

VHS50-N06-A-Z Specifications
