SMC VH310F03 (VH310-F03) - Hand Valve, G3/8 3-position

SMC VH310F03 Hand Valve — 3-position closed-centre, side ported panel mount, G3/8. SMC VH Series hand valve, size 300, 3-position closed centre, F thread G(PF), 3/8 (F03) port, side ported panel mount. Maximum working pressure 1.0 MPa, guaranteed (proof) pressure 1.5 MPa, temperature -5 to 60 C (non-freezing), 90 degree operating angle, no lubrication required.

MPN: VH310-F03 · SKU: VH310F03

VH310-F03 Applications

SMC VH310-F03 is a manually operated hand valve with a 3-position closed-centre spool and G3/8 side ports for panel mounting. The closed-centre position blocks all ports, letting an operator hold or lock a cylinder in place, while the two working positions direct air for manual actuation and setup. Rated to 1.0 MPa with a 90 degree lever action and no lubrication requirement, it is well suited to machine set-up, jigging and manual air-circuit control where a robust, directly operated selector is needed.

VH310-F03 Specifications
