SMC V2115G (V211-5G) - Pilot Valve Assembly, 24 VDC Coil, Grommet Lead Wire Entry
SMC V2115G Pilot Valve Assembly — replacement pilot valve assembly for VF1000/3000/5000 and VP300/500/700 valves. Pilot valve assembly for VF1000/3000/5000 and VP300/500/700 series, 24 VDC, grommet, standard 0.7 MPa pressure specification.
MPN: V211-5G · SKU: V2115G
V211-5G Applications
The SMC V2115G is a replacement pilot valve assembly rather than a complete valve, fitted to VF1000/3000/5000 and VP300/500/700 series solenoid valves when the pilot stage fails or a coil voltage must be changed in the field. Keeping one on the shelf lets maintenance teams restore a manifold station without removing the valve body or breaking pipework, which matters on VV5F1, VV5F3 and VV5F5 manifolds where stations sit shoulder to shoulder. A built-in strainer protects the pilot orifice from line debris and the built-in full-wave rectifier supports AC coil variants.
V211-5G Specifications
| Brand | SMC | Manufacturer Part No. | V211-5G |
| Product Type | Pilot Valve Assembly | Series | V200 (for VF1000/3000/5000, VP300/500/700) |
| Configuration | Pilot Valve Assembly, Grommet or L/M-type | Pressure Specification | Standard (0.7 MPa) |
| Coil Specifications | Standard | Rated Voltage | 5 (24 VDC) |
| Electrical Entry | G (Grommet, Lead Wire Length 300 mm) | Light/Surge Voltage Suppressor | Without Light/Surge Voltage Suppressor |
| Features | Built-in full-wave rectifier (AC); built-in strainer in the pilot valve | Manifold Type No. | VV5F1, VV5F3, VV5F5 |
