SMC TU0604W100 (TU0604W-100) - Polyurethane Tubing, Ø6 x Ø4, White 100 m

SMC TU0604W100 Polyurethane Tubing — Ø6 x Ø4 mm, white, 100 m roll. SMC TU Series polyurethane tubing, Ø6 mm O.D. x Ø4 mm I.D., white. Max. operating pressure 0.8 MPa at 20°C (0.65 MPa at 40°C, 0.5 MPa at 60°C). Operating temperature -20 to +60°C. Min. bending radius 15 mm. Supplied as a 100 m roll. Compatible with One-touch, Insert, Self-align and Miniature fittings.

MPN: TU0604W-100 · SKU: TU0604W100

TU0604W-100 Applications

General-purpose pneumatic tubing for air-line piping, One-touch fittings and actuator connections in factory automation. Its flexible polyurethane construction and 15 mm minimum bending radius allow tight routing in compact machinery, while the white colour supports clear circuit identification. Rated to 0.8 MPa at 20°C across a -20 to +60°C range, it is well suited to control-air and low-pressure distribution lines on assembly and packaging equipment.

TU0604W-100 Specifications
