SMC TRBU1065BU20 (TRBU1065BU-20) - Flame-Resistant Polyurethane Tubing, Ø10 x Ø6.5, Blue 20 m

SMC TRBU1065BU20 Flame-Resistant Polyurethane Tubing — Ø10 x Ø6.5, Blue, 20 m. SMC TRBU1065BU-20 is a flame-resistant double-layer polyurethane tubing with Ø10 mm outer diameter and Ø6.5 mm inner diameter, supplied as a 20 m roll. The blue outer layer is a flame-retardant polyolefin equivalent to UL-94 Standard V-0 over a polyurethane inner tube (inner tubing colour is black). Rated for air and water at a maximum operating pressure of 0.8 MPa (at 20°C), ambient and fluid temperature -20 to 60°C (water 0 to 40°C, no freezing), with a minimum bending radius of 27 mm.

MPN: TRBU1065BU-20 · SKU: TRBU1065BU20

TRBU1065BU-20 Applications

Use SMC TRBU1065BU-20 for air and water piping in areas where sparks from spot welders or similar equipment pose a fire risk. The blue outer layer aids colour-coded line identification while the flame-retardant polyolefin jacket (UL-94 V-0 equivalent) protects the polyurethane core. The larger Ø10 mm bore suits higher-flow lines and the 20 m roll suits maintenance and smaller machine builds.

TRBU1065BU-20 Specifications
