SMC SY71405WOUQ (SY7140-5WOU-Q) - 5-Port Solenoid Valve, 5/3 Pressure Center Solenoid, M8 Connector Base Mounted

SMC SY71405WOUQ 5-Port Solenoid Valve — 5/3 Pressure Center, Base Mounted, M8 Connector, 24 VDC. SMC SY7000 Series 5-port base-mounted single-unit pilot-operated solenoid valve. 3-position pressure center actuation (type 4), internal pilot, 24 VDC, M8 connector electrical entry without connector cable, with light/surge voltage suppressor (non-polar). Push-turn locking type manual override. Supplied without sub-plate. CE-compliant. Mounts on SS5Y7 manifolds.

MPN: SY7140-5WOU-Q · SKU: SY71405WOUQ

SY7140-5WOU-Q Applications

The SY7140-5WOU-Q is a base-mounted 5/3 pressure-center solenoid valve that pressurises both cylinder ports when de-energised, holding a double-acting cylinder firmly against loads in an intermediate position. The M8 connector electrical entry (without cable) supports quick-connect sensor-style wiring, and the non-polar surge suppressor eases installation. Supplied without sub-plate for manifold or custom base mounting; CE-compliant.

SY7140-5WOU-Q Specifications
