SMC SY54205YO01FQ (SY5420-5YO-01F-Q) - 5-Port Solenoid Valve, 5/3 Exhaust Center Solenoid, G1/8 Port

SMC SY54205YO01FQ 5-Port Solenoid Valve — 5/3 Exhaust Center, G1/8 Port, 24 VDC. SMC SY5000 Series 5-port body-ported single-unit pilot-operated solenoid valve. 3-position exhaust center actuation, 24 VDC, DIN (EN175301-803) terminal electrical entry without connector. A/B port size 1/8 with G thread. Push-turn locking type manual override. Power consumption 0.1 W with power-saving circuit. CE-compliant. Combined mounting of 3-port and 5-port valves possible; mounts on SS5Y5 manifolds.

MPN: SY5420-5YO-01F-Q · SKU: SY54205YO01FQ

SY5420-5YO-01F-Q Applications

The SY5420-5YO-01F-Q is a 5/3 exhaust-center solenoid valve that vents both cylinder ports when de-energised, allowing a double-acting cylinder to be moved freely by hand or external load. It is used where a cylinder must float or be manually repositioned during setup and for safe de-pressurisation. DIN terminal wiring and G1/8 body ports suit European installations, and the unit is CE-compliant.

SY5420-5YO-01F-Q Specifications
