SMC SY51205YO01FX10Q (SY5120-5YO-01F-X10-Q) - 5 Port Solenoid Valve, 24 VDC Coil, X10 Through-hole Side Mounting

Name: SMC SY51205YO01FX10Q (SY5120-5YO-01F-X10-Q) - 5 Port Solenoid Valve, 24 VDC Coil, X10 Through-hole Side Mounting
Brand: SMC
SKU: SY51205YO01FX10Q
Price: 205.00 AED
Availability: BackOrder

Brand: SMC|Part No: SY51205YO01FX10Q

AED 205.00

Quantity

Add to Quote

SMC SY51205YO01FX10Q 5 Port Solenoid Valve — X10 made-to-order through-hole side mounting on a G1/8 threaded port. SY5000 series, 2 position single, 24 VDC, DIN (EN175301-803) terminal without connector, without light/surge voltage suppressor, push-turn locking manual override, 1/8 A/B port, G thread, made to order through-hole side mounting SY-X10, CE-compliant.

MPN: SY5120-5YO-01F-X10-Q · SKU: SY51205YO01FX10Q

SY5120-5YO-01F-X10-Q Applications

The SMC SY51205YO01FX10Q is ordered against SMC's X10 made-to-order option, which adds through-hole side mounting to the valve body, and it uses a G1/8 threaded port rather than a push-in fitting. It is used in machine frames and panels where the valve is bolted directly to a bracket or plate through its own body. It suits OEM builds with a fixed mounting pattern, retrofits replacing a side-bolted valve, and CE-marked export equipment on BSPP piping. The DIN EN175301-803 entry ships without a connector so the correct cable gland can be chosen.

SY5120-5YO-01F-X10-Q Specifications

Brand	SMC	Manufacturer Part No.	SY5120-5YO-01F-X10-Q
Product Type	5 Port Solenoid Valve	Series	SY5000
Model	SY5120	Type Of Actuation	2 Position Single
Coil Specifications	Standard	Rated Voltage	24 VDC
Electrical Entry	DIN (EN175301-803) Terminal Without Connector	Light/Surge Voltage Suppressor	Without Light/Surge Voltage Suppressor
Manual Override	Push-turn Locking Type	A/B Port Size	1/8
Thread Type	G	Bracket	None
Made To Order	X10 Through-hole Side Mounting SY-X10	CE-compliant	CE-compliant
Valve Construction	Body Ported / Single Unit	Power Consumption	0.1 W (with power saving circuit)
