SMC SY51203DZ01FQ (SY5120-3DZ-01F-Q) - 5 Port Solenoid Valve, 110 VAC Coil, G1/8 Port
SMC SY51203DZ01FQ 5 Port Solenoid Valve — 110 VAC [115 VAC] mains-voltage coil, not the 24 VDC used across the rest of the family. SY5000 series, 2 position single, 110 VAC [115 VAC] rated voltage, DIN terminal, with light/surge voltage suppressor, push-turn locking manual override, 1/8 A/B port, G thread, CE-compliant, body ported single unit.
MPN: SY5120-3DZ-01F-Q · SKU: SY51203DZ01FQ
SY5120-3DZ-01F-Q Applications
The defining difference of the SMC SY51203DZ01FQ is its coil: the 3 in the order code specifies 110 VAC [115 VAC], where almost every sibling in this family runs on 24 VDC. It is used on plant and machinery switched directly from mains-voltage control circuits rather than a PLC 24 V rail. It suits older relay-logic panels, process equipment on 110/115 V control transformers, and CE-marked export machinery on BSPP piping. Its DIN terminal with light and surge suppressor gives a visible indication and protects upstream contacts from switching spikes.
SY5120-3DZ-01F-Q Specifications
| Brand | SMC | Manufacturer Part No. | SY5120-3DZ-01F-Q |
| Product Type | 5 Port Solenoid Valve | Series | SY5000 |
| Model | SY5120 | Type Of Actuation | 2 Position Single |
| Coil Specifications | Standard | Rated Voltage | 110 VAC [115 VAC] |
| Electrical Entry | DIN Terminal | Light/Surge Voltage Suppressor | With Light/Surge Voltage Suppressor |
| Manual Override | Push-turn Locking Type | A/B Port Size | 1/8 |
| Thread Type | G | Bracket | None |
| Made To Order | Standard | CE-compliant | CE-compliant |
| Valve Construction | Body Ported / Single Unit | Power Consumption | 0.1 W (with power saving circuit) |
| Manifold Type No. | SS5Y5 |
Equivalents & Cross-Reference
Cross-references are functional equivalents provided for guidance only. Verify port size, flow, and pressure rating before substituting.
