SMC SY31405LZ01 (SY3140-5LZ-01) - 5 Port Solenoid Valve, Rc 1/8 Sub-Plate Port, 300 mm Lead Wire
SMC SY31405LZ01 5 Port Solenoid Valve — base mounted on a 1/8 sub-plate rather than body ported. 5 port, 2 position single solenoid, 24 VDC, base mounted single unit, 1/8 port mounted with sub-plate, L-type plug connector with 300 mm lead wire, light/surge voltage suppressor, internal pilot.
MPN: SY3140-5LZ-01 · SKU: SY31405LZ01
SY3140-5LZ-01 Applications
The SMC SY31405LZ01 is base mounted onto a 1/8 sub-plate instead of being body ported, so the piping stays with the plate when the valve is removed. It is used in assembly, packaging and handling machines that need larger 1/8 porting than the M5 body ported SY3120 offers. It is suited to higher flow single actuator circuits, panels where valves are changed without breaking pipework, and machines standardised on Rc threads. Sub-plate mounting means a failed valve is swapped in minutes with the air lines left undisturbed.
SY3140-5LZ-01 Specifications
| Brand | SMC | Manufacturer Part No. | SY3140-5LZ-01 |
| Product Type | 5 Port Solenoid Valve, Base Mounted, Single Unit | Series | 3 - SY3000 |
| Type Of Actuation | 1 - 2 Position Single | Pilot Type | Internal Pilot |
| Coil Specifications | Standard | Rated Voltage | 5 - 24 VDC |
| Electrical Entry | L - L-type Plug Connector With Lead Wire (Length 300 mm) | Light/Surge Voltage Suppressor | Z - With Light/Surge Voltage Suppressor |
| Manual Override | Push-turn Locking Type | Port Size | 01 - 1/8 (Mounted With Sub-Plate) |
| Thread Type | Rc | Made To Order | Standard |
| CE-compliant | - |
