SMC SY30MN6P3 (SY30M-N6-P-3) - Interface Regulator for SY Series, 1(P) Port Regulation, psi Pressure Gauge
SMC SY30MN6P3 Interface Regulator for SY Series — 1(P) port regulation with psi pressure gauge for even-numbered stations. SY3000 series, 1(P) port regulation, pressure gauge with psi display, for 3-position valves.
MPN: SY30M-N6-P-3 · SKU: SY30MN6P3
SY30M-N6-P-3 Applications
The SMC SY30MN6P3 is an interface regulator that mounts between an SY3000 valve and its manifold base to regulate the 1(P) supply port at an individual station. It is used in packaging, assembly and material-handling machines where one actuator on a shared manifold needs a lower or independently tuned pressure. It suits station-level force control, energy reduction on return strokes, and gentle gripping of delicate parts. Because it regulates at the station rather than the whole manifold, it avoids re-plumbing and keeps the compact SY3000 footprint, and the psi-display gauge variant is intended for even-numbered stations.
SY30M-N6-P-3 Specifications
| Series | SY3000 | Manufacturer Part No. | SY30M-N6-P-3 |
| Pressure Gauge Option | Pressure Gauge With psi Display (For Even Number Station) | Regulating Port | 1(P) Port |
| Applicable Valve | For 3-Position | Product Type | Interface Regulator For SY Series |
| Part Number Decode | SY30M | N6 = Pressure Gauge With psi Display (For Even Number Station) | P = 1(P) Port | 3 = For 3-Position | Verification Note | Confirmed on SMC's WEB Catalog as SY30M-N6-P-3; the decoder's Value column reconstructs the as-listed SKU exactly. This part is an interface regulator accessory, not a solenoid valve. |
Trusted by
SMC SY30MN6P3 (SY30M-N6-P-3) - Interface Regulator for SY Series, 1(P) Port Regulation, psi Pressure Gauge
Brand: SMC
