SMC RSDQB5020DZ (RSDQB50-20DZ) - Stopper Cylinder, 50 mm Bore, 20 mm Stroke
SMC RSDQB5020DZ Stopper Cylinder — 50 mm bore with through-hole mounting, built-in magnet and double acting operation. 50 mm bore, 20 mm stroke, double acting, built-in magnet for auto switch mounting, through-hole mounting, Rc port thread, round bar piston rod end.
MPN: RSDQB50-20DZ · SKU: RSDQB5020DZ
RSDQB50-20DZ Applications
The SMC RSDQB5020DZ pairs a 50 mm bore with through-hole mounting, a built-in magnet and double acting operation, which sets it apart from the tapped-mount and non-magnet variants of the RSQ-Z range. It is used to stop and release pallets and workpieces on conveyor and transfer lines in automotive and general assembly plants. It is suited to pallet stopping, workpiece indexing, and positioning duty where the stopper must hold a fixed mounting height. The built-in magnet lets auto switches mount on any of four faces for position feedback without adding external hardware.
RSDQB50-20DZ Specifications
| Brand | SMC | Manufacturer Part No. | RSDQB50-20DZ |
| Product Type | Stopper Cylinder, Fixed Mounting Height | Series | RSQ-Z Series Stopper Cylinder Fixed Mounting Height |
| With Auto Switch (Built-in Magnet) | D - With Auto Switch | Mounting Style | B - Through-hole (Standard) |
| Bore Size | 50 - Bore Size 50 mm | Port Thread Type | M Thread (dia. 12-16); Rc (dia. 20-50) |
| Cylinder Stroke | 20 - Standard Stroke 20 mm | Action | D - Double Acting |
| Piston Rod End Type | Round Bar | Mounting Bolt | None |
| Auto Switch | Without Auto Switch | Number Of Auto Switches | 2 pcs. Or None |
| Made To Order | Standard |
