SMC MXS12100 (MXS12-100) - Air Slide Table, 12 mm Bore, 100 mm Stroke
SMC MXS12100 Air Slide Table — cross roller guide with dual rod function, giving twice the output of a conventional cylinder. 12 mm bore, 100 mm stroke, cross roller guide, dual rod function, standard type.
MPN: MXS12-100 · SKU: MXS12100
MXS12-100 Applications
A cross roller guide and dual rod function separate the SMC MXS12100 from the recirculating-guide MXQ tables: the dual rod gives twice the output of a conventional cylinder, and the cross roller guide moves smoothly without looseness. It is used in precision assembly work, electronics production and inspection equipment, and is suited to accurate part positioning, long 100 mm transfer moves and loading into tight fixtures. The worktable is integrated compactly, keeping the unit light for the rigidity offered.
MXS12-100 Specifications
| Brand | SMC | Manufacturer Part No. | MXS12-100 |
| Product Type | Air Slide Table | Series | MXS |
| Bore Size | 12 mm | Cylinder Stroke | 100 mm |
| Port Thread Type | M Thread (Φ6-Φ16), Rc (Φ20-Φ25) | Adjuster Option | None |
| Functional Option | Standard | Auto Switch | Without Auto Switch |
| Number of Auto Switches | 2 pcs. Or None | Made to Order | Standard |
| Guide Type | Cross roller guide | Construction | Integrated worktable, dual rod function |
