SMC MHSL350D (MHSL3-50D) - Air Gripper, Parallel Style, Slide Guide Type, Round Body, 3-Finger Long Stroke, 50 mm Bore, 3-Finger Long Stroke Type
SMC MHSL350D Air Gripper, Parallel Style, Slide Guide Type, Round Body, 3-Finger Long Stroke — 3-finger round-body slide-guide design at 50 mm bore, the only 3-jaw chuck in this set. Parallel style slide guide air gripper, round body, 3-finger long stroke type, 50 mm bore, M thread port, repeatability +/-0.01 mm.
MPN: MHSL3-50D · SKU: MHSL350D
MHSL3-50D Applications
The SMC MHSL350D is the only 3-finger round-body chuck in this set, centring a workpiece on three jaws instead of gripping it between two, at a 50 mm bore. It is used in press-fit stations, CNC machine tending, and cylindrical-part assembly. It is suited for gripping cylindrical workpieces, press-fitting operations where external force is applied to the gripper, and removing parts with through-holes via the centre pusher. SMC notes it is vertically compact and lightweight due to the wedge shaped cam construction, holds repeatability of +/-0.01 mm, and the long stroke type gives strokes two times longer than the standard type.
MHSL3-50D Specifications
| Brand | SMC | Manufacturer Part No. | MHSL3-50D |
| Product Type | Air Gripper, Parallel Style, Slide Guide Type, Round Body, 3-Finger Long Stroke Type | Series | MHSL3 Series |
| Bore Size | 50 mm | Port Thread Type | M thread (series range: M thread for 16 to 63; Rc for 80 to 125) |
| Repeatability | +/-0.01 mm | Stroke Type | Long stroke type - strokes two times longer than the standard type |
| Auto Switch | Without Auto Switch | Number Of Auto Switches | 2 pcs. Or None |
| Made To Order | Standard |
