SMC MGPM63TF150Z (MGPM63TF-150Z) - Compact Guide Cylinder, 63 mm Bore, 150 mm Stroke
SMC MGPM63TF150Z Compact Guide Cylinder — 150 mm stroke at 63 mm bore for deep-reach vertical travel. 63 mm bore, 150 mm stroke, G port thread (TF), slide bearing guide, built-in magnet, without auto switch.
MPN: MGPM63TF-150Z · SKU: MGPM63TF150Z
MGPM63TF-150Z Applications
The SMC MGPM63TF150Z provides 150 mm of deep-reach vertical travel on the 63 mm bore. It is used for reaching into bins, totes and deep fixtures, for lowering tooling onto tall workpieces, and for long-stroke ejector and knockout duty. At this travel the guided construction matters most: the twin rods and slide bearings hold the plate square where an unguided rod would deflect. The G-threaded ports suit BSPP fittings common on European and Gulf machine builds.
MGPM63TF-150Z Specifications
| Brand | SMC | Manufacturer Part No. | MGPM63TF-150Z |
| Product Type | Compact Guide Cylinder | Series | MGP-Z |
| Bearing Type | M - Slide Bearing | Bore Size | 63 mm |
| Port Thread Type | TF - G | Cylinder Stroke | Standard Stroke 150 mm |
| Stroke Adjustment Symbol | None | Auto Switch | Without Auto Switch (With Built-in Magnet) *When Made To Order Is XB6 Without Built-in Magnet |
| Number Of Auto Switches | 2 pcs. Or None | Made To Order | Standard |
| Cushion | Without air cushion | Replacement Seal Kit | MGP63-Z-PS |
