SMC KQH0802 (KQH08-02) - One-touch Male Connector, ø8 mm tube, R1/4 male connector

SMC KQH0802 One-touch Male Connector — ø8 mm metal male connector, R1/4 thread. KQ Series metal one-touch male connector joining ø8 mm tube to R1/4 (Rc1/4) male taper thread. Type H body; tube O.D. ø8 mm; bore code 02 = R1/4 Rc1/4; without thread sealant. Brass body (nickel-plated option), black body with blue release button. Operating pressure vacuum -100 kPa to 1.0 MPa; ambient/fluid temperature -5 to 60°C. Push-in one-touch connection.

MPN: KQH08-02 · SKU: KQH0802

KQH08-02 Applications

The KQH08-02 connects an ø8 mm tube to an R1/4 threaded port using a durable metal (brass) one-touch body, ideal for tapping compressed air into cylinders, valves, manifolds and equipment ports. Supplied without factory thread sealant, it lets the installer apply PTFE tape or sealant as required. Rated from vacuum to 1.0 MPa, the metal construction resists vibration and harsh conditions in machine tools, automation and general pneumatic circuits.

KQH08-02 Specifications
