SMC KKA3P02M1 (KKA3P-02M-1) - S-Coupler Plug, Rc 1/4 male thread, Stainless Steel Plug

SMC KKA3P02M1 S-Coupler Plug — Stainless steel plug, male thread without check valve. KKA series S-coupler plug, body size 3 (1/8), port 02 (R/Rc 1/4), male thread type with seal, without check valve (option 1). Body material SUS304; seal material FKM; non-greased specification (standard). Fluid: water, air. Slim body / large effective-area construction using no steel balls or valve springs.

MPN: KKA3P-02M-1 · SKU: KKA3P02M1

KKA3P-02M-1 Applications

The KKA3P-02M-1 is the plug half of SMC's KKA stainless steel S-coupler series in the without-check-valve variant, giving an unobstructed full-bore flow path for water and air lines. Its SUS304 body and FKM seal suit corrosive or washdown duty, and the non-greased construction avoids fluid contamination. Omitting the check valve maximizes flow and is chosen where fluid retention on disconnect is not required. The male Rc 1/4 thread mounts directly into manifolds, tools, or equipment ports.

KKA3P-02M-1 Specifications
