SMC KKA3P02M (KKA3P-02M) - S-Coupler Plug, Rc 1/4 male thread, Stainless Steel Plug

SMC KKA3P02M S-Coupler Plug — Stainless steel plug, male thread with check valve. KKA series S-coupler plug, body size 3 (1/8), port 02 (R/Rc 1/4), male thread type with seal, built-in check valve. Body material SUS304; seal material FKM; non-greased specification (standard). Fluid: water, air. Slim body / large effective-area construction using no steel balls or valve springs.

MPN: KKA3P-02M · SKU: KKA3P02M

KKA3P-02M Applications

The KKA3P-02M is the plug half of SMC's KKA stainless steel S-coupler series, providing a quick-connect/disconnect joint for water and air lines. Its SUS304 body and FKM seal suit corrosive or washdown environments, and the non-greased construction avoids fluid contamination. The built-in check valve minimizes fluid loss on disconnection, while the ball-free, spring-free design keeps the flow path open and the body slim. The male Rc 1/4 thread mounts directly into manifolds, tools, or equipment ports.

KKA3P-02M Specifications
