SMC IZF10P (IZF10-P) - Fan Type Ionizer, 0.66 m3/min air flow, PNP output

SMC IZF10P Fan Type Ionizer — Fan type static neutralizer, PNP output, 0.66 m3/min air flow. IZF10 series fan type ionizer (static neutralizer) without flow rate adjustment function, PNP type. Maximum air flow 0.66 m3/min. Ion generation method: corona discharge. Offset voltage (ion balance) within +/-13 V. Power supply 24 VDC +/-10%, power consumption 250 mA or less. Switch output: PNP open collector. Ambient temperature operating 0 to 50 C, stored -10 to 60 C. Ambient humidity 35 to 80% RH (no condensation). Weight 280 g (with bracket 360 g).

MPN: IZF10-P · SKU: IZF10P

IZF10-P Applications

Compact fan type ionizer that neutralizes static electricity using ambient air, ideal where a compressed air supply is inconvenient or unavailable. It projects static-eliminating ions over a work area to prevent dust attraction, jams and ESD damage on electronics, film, plastics and assembly lines. The PNP open-collector output signals status to a controller, and the corona-discharge emitter delivers rapid neutralization with a maintainable +/-13 V ion balance in a slim, wall- or bracket-mountable body.

IZF10-P Specifications
