SMC ITV201031F2BN3Q (ITV2010-31F2BN3-Q) - Electro-Pneumatic Regulator, G1/4 Port, 0.1 MPa Pressure Range
SMC ITV201031F2BN3Q Electro-Pneumatic Regulator — CE-compliant Q variant on the larger 2000 body with a low 0.005 to 0.1 MPa range and G1/4 port. 0.005 to 0.1 MPa set pressure range, 0 to 10 VDC voltage input signal, 1 to 5 VDC analog monitor output, G1/4 port, flat bracket, 24 VDC, bar display, IP65.
MPN: ITV2010-31F2BN3-Q · SKU: ITV201031F2BN3Q
ITV2010-31F2BN3-Q Applications
The CE-compliant Q variant on the larger 2000 body, with its low 0.005 to 0.1 MPa range and G1/4 port, is what sets the SMC ITV201031F2BN3Q apart from the higher-range ITV siblings: it resolves gentle pressures finely while the 1/4 port passes far more flow than a 1000-body unit. It is used in printing, converting, glass handling and laminating machinery across CE-marked plant. It is suited for delicate web and nip tension control, low-force clamping on fragile parts, and air-bearing or balancer supply. The 1 to 5 VDC monitor output reports actual pressure back to the PLC for closed-loop trimming.
ITV2010-31F2BN3-Q Specifications
| Brand | SMC | Manufacturer Part No. | ITV2010-31F2BN3-Q |
| Product Type | Electro-Pneumatic Regulator | Series | ITV2000 (ITV2010, 2000 body type) |
| Set Pressure Range | 0.005 to 0.1 MPa | Minimum Supply Pressure | Set pressure + 0.1 MPa |
| Maximum Supply Pressure | 0.2 MPa | Input Signal | Voltage type, 0 to 10 VDC (input impedance approx. 6.5 kOhm) |
| Monitor Output | Analog output, 1 to 5 VDC (load impedance 1 kOhm or more) | Power Supply | 24 VDC +/-10% |
| Current Consumption | 0.12 A or less | Port Size | 1/4, G (BSPP) thread |
| Bracket | Flat bracket | Cable Connector | Without cable connector |
| Pressure Display Unit | bar | Linearity | Within +/-1% F.S. |
| Hysteresis | Within 0.5% F.S. | Repeatability | Within +/-0.5% F.S. |
| Sensitivity | Within 0.2% F.S. | Enclosure | IP65 |
| Operating Temperature | 0 to 50 degC (no condensation) | Weight | Approx. 350 g (2000 body type, without options) |
| Part Number Decode | ITV = electro-pneumatic regulator; 2 = 2000 type; 1 = 0.1 MPa range; 0 = 24 VDC; 3 = voltage input 0 to 10 VDC; 1 = analog monitor output 1 to 5 VDC; F = G thread; 2 = 1/4 port; B = flat bracket; N = without cable connector; 3 = bar display; Q = CE-compliant | Product Status | CE-compliant 'Q' variant superseded by the current ITV1000-3000 series |
Equivalents & Cross-Reference
Cross-references are functional equivalents provided for guidance only. Verify port size, flow, and pressure rating before substituting.
