SMC ITV103031N2N4 (ITV1030-31N2N4) - Electro-Pneumatic Regulator, 0.005 to 0.5 MPa, 1/4 NPT port

SMC ITV103031N2N4 Electro-Pneumatic Regulator — Compact 1000 type, 0.005 to 0.5 MPa, NPT thread, analog output. Compact ITV1000 type electro-pneumatic regulator for stepless control of air pressure proportional to an electrical signal. Set pressure range 0.005 to 0.5 MPa. N = NPT thread. Output N4 = analog monitor output 4 to 20 mA DC (sink type). Power supply 24 VDC +/-10%; current consumption 0.12 A or less. Linearity +/-1% F.S.; hysteresis 0.5% F.S.; repeatability +/-0.5% F.S. Enclosure IP65 equivalent. Max supply pressure 1.0 MPa.

MPN: ITV1030-31N2N4 · SKU: ITV103031N2N4

ITV1030-31N2N4 Applications

The ITV1030-31N2N4 is a compact electro-pneumatic regulator that steplessly controls output air pressure from 0.005 to 0.5 MPa proportional to an electrical input. With NPT porting and a 4 to 20 mA analog monitor output, it feeds the actual pressure back to a PLC or controller for closed-loop proportional control in tension control, air bearings, dispensing and test benches. The compact 1000-type body offers precise, repeatable regulation in confined pneumatic assemblies.

ITV1030-31N2N4 Specifications
