SMC EX600SDN1A (EX600-SDN1A) - SI Unit for DeviceNet, DeviceNet Protocol, PNP 32 Outputs

SMC EX600SDN1A SI Unit for DeviceNet — DeviceNet SI unit, PNP (negative common) output, max 512 I/O. SMC EX600-SDN1A serial interface (SI) unit for DeviceNet, EX600 integrated fieldbus system. Protocol DeviceNet Volume 1 (Ed. 2.1) / Volume 3 (Ed. 1.1); device type communication adapter; slave Group 2 Only Server. Communication speed 125 / 250 / 500 kbps. Configuration via EDS file. I/O occupation area max 512 inputs / 512 outputs. PNP / source, negative common output; 32 outputs (8/16/24/32 selectable). Load: solenoid valve with light/surge voltage suppressor 24 VDC 1.5 W or less (SMC). Fail safe HOLD / CLEAR / Force ON. Short-circuit protection. DeviceNet power supply 11 to 25 VDC. Enclosure IP67 (manifold assembly). Operating temperature -10 to 50 C. Operating humidity 35 to 85% RH (no dew condensation). CE marking, UL (CSA) recognition.

MPN: EX600-SDN1A · SKU: EX600SDN1A

EX600-SDN1A Applications

The EX600-SDN1A is the DeviceNet SI (serial interface) unit that links an SMC EX600 valve manifold and its I/O modules to a DeviceNet network, mapping up to 512 inputs and 512 outputs and driving up to 32 solenoid valve outputs (PNP, negative common). Configured by EDS file at 125/250/500 kbps, it centralises valve and sensor control over a single trunk, replacing multi-core wiring. Fail-safe HOLD/CLEAR/Force ON and IP67 sealing make it suited to packaging, automotive and general factory automation lines running DeviceNet.

EX600-SDN1A Specifications
