SMC EX600DXPC (EX600-DXPC) - Digital Input Unit, 8 Inputs PNP, 8 x M8 Connector

SMC EX600DXPC Digital Input Unit — 8-input PNP digital input unit, 8 x M8 (3-pin), 1 input per connector. SMC EX600-DXPC digital input unit for the EX600 integrated I/O fieldbus system. PNP (negative common) input, 8 input channels arranged as 1 channel per connector across 8 x M8 (3-pin) socket connectors. Rated input current 9 mA or less, input resistance 2.7 kOhm. Power supply voltage 24 VDC Class 2 (2 A). ON voltage/current 17 V or more / 5 mA or more; OFF voltage/current 5 V or less / 1 mA or less. Sensor supply 24 VDC from the control/input power supply; compatible with 2-wire and 3-wire PNP sensors. Short-circuit protection. Enclosure IP67 (manifold assembly). Operating temperature -10 to 50 C. Operating humidity 35 to 85% RH (no dew condensation).

MPN: EX600-DXPC · SKU: EX600DXPC

EX600-DXPC Applications

The EX600-DXPC adds eight PNP digital inputs to an SMC EX600 fieldbus manifold, using eight compact M8 3-pin sockets with one channel each for high-density sensor connection. It consolidates auto switch and sensor signals onto the EX600 serial link to the SI unit, reducing wiring on valve manifolds and remote I/O. With IP67 sealing and short-circuit protection it suits packaging, assembly and material-handling machines where many discrete inputs must be gathered onto DeviceNet, PROFINET, EtherNet/IP and similar networks.

EX600-DXPC Specifications
