SMC EX500IE5 (EX500-IE5) - Input Block, EX500 Input Block, M12 Connector

SMC EX500IE5 Input Block — Extension input block, M12 connector, PNP sensor input. Extension input block for the EX500 input unit (EX500-IB1) of the gateway-type serial transmission system. PNP sensor input via M12 connector. Input device supply 24 VDC. Green LED power indication. Enclosure IP65. Mounts onto the EX500 input manifold base.

MPN: EX500-IE5 · SKU: EX500IE5

EX500-IE5 Applications

The EX500-IE5 is an extension input block for the EX500-IB1 input manifold in an SMC EX500 serial transmission system, providing PNP sensor inputs through M12 connectors with LED power indication and IP65 protection. It expands the manifold's input capacity for gathering 3-wire sensor signals into the fieldbus network. It is used on machine-mounted pneumatic automation in packaging, automotive and assembly applications built around EX500 manifolds.

EX500-IE5 Specifications
