SMC EVFS11205YO01FQ (EVFS1120-5YO-01F-Q) - 5 Port Pilot Solenoid Valve, Metal Seal, Body Ported, G1/8 Port, 24 VDC Coil
SMC EVFS11205YO01FQ 5 Port Pilot Solenoid Valve, Metal Seal, Body Ported — 2-position single solenoid with G1/8 port. 5 port 2 position single solenoid, G1/8 (PF) ports, Cv 0.38, 24 VDC coil, DIN 43650B electrical entry without connector, individual pilot exhaust, metal seal construction, max. operating pressure 1.0 MPa.
MPN: EVFS1120-5YO-01F-Q · SKU: EVFS11205YO01FQ
EVFS1120-5YO-01F-Q Applications
The SMC EVFS11205YO01FQ is used in general factory automation, packaging, automotive assembly and machine tool applications where a compact 5 port valve must drive a double acting cylinder. It is suited for high-cycle cylinder control, manifold-mounted valve banks, and installations that need a robust valve able to run non-lubricated. Its metal seal main valve gives long service life and stable switching at high frequency, while the DIN 43650B electrical entry allows quick field wiring and connector replacement without disturbing the valve body or piping.
EVFS1120-5YO-01F-Q Specifications
| Brand | SMC | Manufacturer Part No. | EVFS1120-5YO-01F-Q |
| Product Type | 5 Port Pilot Solenoid Valve, Metal Seal, Body Ported | Series | VFS1000 |
| Ordering Source Area Code | E (Europe) | Valve Configuration | 2 position single solenoid |
| Pilot Exhaust | Individual exhaust | Port Size | G 1/8 (PF thread) |
| Flow Rate Characteristics | C = 1.7 dm3/(s.bar), b = 0.22, Cv = 0.38 (4/2, P to A/B) | Fluid | Air |
| Maximum Operating Pressure | 1.0 MPa | Minimum Operating Pressure | 0.1 MPa (2 position) |
| Proof Pressure | 1.5 MPa | Response Time | 15 ms or less |
| Coil Rated Voltage | 24 VDC | Allowable Voltage Fluctuation | -15 to +10% of rated voltage |
| Power Consumption (DC) | 1.8 W | Coil Insulation Type | Class B or equivalent (130 C) |
| Electrical Entry | DIN connector DIN 43650B (Y type), supplied without connector (YO) | Manual Override | Non-locking push type (flush) |
| Ambient and Fluid Temperature | -10 to 60 C | Lubrication | Non-lube |
| Enclosure | Dustproof (equivalent to IP50) | Impact/Vibration Resistance | 150/50 m/s2 |
| Mounting | Body ported |
Equivalents & Cross-Reference
Cross-references are functional equivalents provided for guidance only. Verify port size, flow, and pressure rating before substituting.
