ASCO EF8316G054 3-Way Solenoid Valve — 3/8" brass body, normally closed, high-flow pilot. Series 316 (8316) high-flow 3-way solenoid valve, 3/2 normally closed, 3/8" NPT brass body, used to pilot large actuators.
MPN / SKU: EF8316G054
EF8316G054 Applications
The ASCO EF8316G054 is a high-flow 3-way solenoid valve from Series 316, designed to pilot large actuators and provide quick closing of large control valves. With a 3/2 normally closed function and a 3/8" NPT brass body, it delivers fast, reliable actuation for process automation, valve piloting, and pneumatic control in refineries, chemical plants, and general industrial service. The diaphragm-poppet construction achieves tight shutoff on air, inert gas and liquid media. Multiple coil classes and AC/DC voltages are available to match the installation, making it a versatile choice wherever a compact high-capacity pilot valve is required.
EF8316G054 Specifications
| Series | 316 (8316) | Type | Solenoid Valve |
| Function | 3/2 Normally Closed | Port Size | 3/8" NPT |
| Body Material | Brass | Sealing | NBR |
| Media | Air, inert gas, liquids | Design | High-flow pilot / diaphragm poppet |
Trusted by
ASCO EF8316G054 - 3-Way Solenoid Valve, 3/2 NC, 3/8" NPT
Brand: ASCO
