SMC AW60N10BGB (AW60-N10BG-B) - Modular Filter Regulator, NPT1 Port, Bracket and Gauge

SMC AW60N10BGB Modular Filter Regulator — NPT1 port largest-body unit with bracket and round pressure gauge, 5 micron element. Combined modular filter and regulator, body size 60 (largest AW), NPT1 port, 5 micrometer nominal filtration, polycarbonate bowl with bowl guard, relieving type regulator, set pressure range 0.05 to 0.85 MPa, max operating pressure 1.0 MPa, proof pressure 1.5 MPa, ambient/fluid temperature -5 to 60 C, drain capacity 45 cm3, supplied with mounting bracket (2 screws) and round pressure gauge. Weight approx 2.00 kg.

MPN: AW60-N10BG-B · SKU: AW60N10BGB

AW60-N10BG-B Applications

Largest AW-body modular filter regulator with NPT1 porting for high-volume air-preparation mains, integrating 5 micron filtration and relieving pressure regulation in one unit supplied with a mounting bracket and round pressure gauge for direct read-out and easy panel or frame mounting. The generous 1 inch porting suits main-line air conditioning ahead of large machinery, presses and multi-branch pneumatic systems.

AW60-N10BG-B Specifications
