SMC AW40N02GH2RZD (AW40-N02GH-2RZ-D) - Modular Filter Regulator, NPT 1/4 Port, Metal Bowl
SMC AW40N02GH2RZD Modular Filter Regulator — NPT 1/4 port with metal bowl and right-to-left flow. Modular type filter regulator with backflow function option, body size 40, NPT pipe thread, 1/4 port, round type pressure gauge with limit indicator and set nut, metal bowl, relieving type exhaust, flow direction right to left, psi and degF unit labelling.
MPN: AW40-N02GH-2RZ-D · SKU: AW40N02GH2RZD
AW40-N02GH-2RZ-D Applications
The SMC AW40N02GH2RZD is the NPT 1/4 build with a metal bowl and reversed right-to-left flow, which separates it from the G-threaded, polycarbonate-bowl siblings. It is used in air preparation on machinery piped to North American NPT standards. It is suited to plants specifying imperial psi gauges, installations where a metal bowl is mandated for impact or lamp resistance, and layouts whose supply enters from the opposite side. The metal bowl withstands compressor oils and mechanical knocks that would craze a polycarbonate bowl.
AW40-N02GH-2RZ-D Specifications
| Brand | SMC | Manufacturer Part No. | AW40-N02GH-2RZ-D |
| Product Type | Modular Filter Regulator | Series | AW20(K)-D~AW60(K)-D |
| SMC Series Description | AW20(K)-D~AW60(K)-D Series Modular Type Filter Regulator (With Backflow Function Option) | Body Size | 40 |
| With Backflow Function | Without Backflow Function | Pipe Thread Type | N - NPT |
| Port Size | 02 - 1/4 | Bracket | Without Bracket |
| Float Type Auto Drain | Without Auto Drain | Digital Pressure Switch | Without Digital Pressure Switch |
| Pressure Gauge/Mounting Option | GH - Round Type Pressure Gauge (With Limit Indicator), With Set Nut | Set Pressure | 0.05 To 0.85 MPa Setting |
| Bowl | 2 - Metal Bowl | Drain Port Option a | With Drain Cock |
| Exhaust Mechanism | Relieving Type | Flow Direction | R - Flow Direction: Right To Left |
| Unit | Z - Unit On Product Label: psi, degF; Pressure Gauge: MPa/psi Dual Scale | Made To Order | Standard |
