SMC AW4003BG2ND (AW40-03BG-2-N-D) - Modular Filter Regulator, Rc3/8 Port, With Metal Bowl

SMC AW4003BG2ND Modular Filter Regulator — Rc3/8 Port, Round Gauge, Metal Bowl, Non-Relieving, Auto Drain (N.O.). SMC Series AW modular filter regulator, body size 40, Rc3/8 port, with bracket, round type pressure gauge, metal bowl (2), non-relieving exhaust and float type auto drain (N.O.). 5 micron nominal filtration. Set pressure 0.05 to 0.85 MPa, max operating pressure 1.0 MPa, proof pressure 1.5 MPa, ambient/fluid temp -5 to 60 C.

MPN: AW40-03BG-2-N-D · SKU: AW4003BG2ND

AW40-03BG-2-N-D Applications

Heavy-duty body-size-40 filter-regulator with Rc3/8 ports, mounting bracket, round pressure gauge and a durable metal bowl fitted with a normally-open float auto drain for hands-free condensate removal. The non-relieving regulator suits sealed downstream circuits. Suited to demanding industrial air-preparation duties, high-flow lines and installations where the polycarbonate bowl would be exposed to impact or aggressive atmospheres.

AW40-03BG-2-N-D Specifications
