SMC AW30032A (AW30-03-2-A) - Filter Regulator, Rc 3/8 Port

SMC AW30032A Filter Regulator — Rc 3/8 port, size 30, metal bowl, no auto drain, no gauge, no bracket. SMC AW30-A Series modular filter regulator, body size 30, Rc 3/8 port size. Combines a filter and regulator in one body. Semi-standard metal bowl variant (option 2). Without mounting option, without auto drain, without pressure gauge. Element and bowl in one piece for easy hand replacement. Set pressure range 0.05 to 0.7 MPa, with drain cock, relieving type, flow left to right, pressure gauge in MPa. To be discontinued (September 2025); replacement series AW20-AW40-D.

MPN: AW30-03-2-A · SKU: AW30032A

AW30-03-2-A Applications

Provides filtered and pressure-regulated compressed air in one compact unit for machine air preparation, reducing footprint and piping. This AW30-A size 30 with Rc 3/8 ports uses a semi-standard metal bowl for higher mechanical durability in demanding environments. The one-piece element-and-bowl simplifies maintenance. Note this A-series configuration is being discontinued (replacement AW20-AW40-D).

AW30-03-2-A Specifications
