SMC AW20N02GH2RZD (AW20-N02GH-2RZ-D) - Modular Filter Regulator, NPT1/4 Port, With Round Pressure Gauge

SMC AW20N02GH2RZD Modular Filter Regulator — NPT1/4 port, round pressure gauge with panel-mount set nut, metal bowl, right-to-left flow, psi/imperial units. SMC AW20-N02GH-2RZ-D modular filter regulator combining a 5 micron air filter and relieving pressure regulator in one body. NPT1/4 ports, metal bowl, maximum operating pressure 1.0 MPa, set pressure range 0.05 to 0.85 MPa, ambient and fluid temperature -5 to 60 C. Configured with round type pressure gauge (with limit indicator), panel-mount set nut, right-to-left flow direction and imperial (psi, F) name plate / bowl caution plate with MPa/psi dual scale pressure gauge. Drain capacity 8 cm3..

MPN: AW20-N02GH-2RZ-D · SKU: AW20N02GH2RZD

AW20-N02GH-2RZ-D Applications

Installed at the inlet of a pneumatic system to filter particulates and regulate supply pressure in one modular unit. The panel-mount set nut allows the unit to be fitted through a control panel with the adjustment knob accessible from the front, while the right-to-left flow direction accommodates non-standard piping layouts. The NPT1/4 thread and psi/imperial labelling suit North American installations, the metal bowl adds durability and the round gauge gives clear indication. Suited to panel-mounted controls and machinery requiring clean, stable air.

AW20-N02GH-2RZ-D Specifications
