SMC AW2002BCE2D (AW20-02BCE2-D) - Modular Filter Regulator, Rc1/4 Port, With N.C. Auto Drain

SMC AW2002BCE2D Modular Filter Regulator — Rc1/4 port, with bracket, N.C. auto drain, NPN digital pressure switch (top entry), N.O. float auto drain option. SMC AW20-02BCE2-D modular filter regulator combining a 5 micron air filter and relieving pressure regulator in one body. Rc1/4 ports, polycarbonate bowl, maximum operating pressure 1.0 MPa, set pressure range 0.05 to 0.85 MPa, ambient and fluid temperature -5 to 60 C. Supplied with mounting bracket, N.C. float type auto drain, NPN digital pressure switch (wiring top entry) and N.O. float type auto drain option. Drain capacity 8 cm3..

MPN: AW20-02BCE2-D · SKU: AW2002BCE2D

AW20-02BCE2-D Applications

Used at the inlet of pneumatic circuits to filter particulates and regulate downstream air pressure in a single compact unit. The N.C. float auto drain automatically discharges collected condensate without manual intervention, while the integrated NPN digital pressure switch provides electrical feedback and monitoring of the regulated pressure. The mounting bracket eases panel or frame installation. Suited to automated machinery, assembly lines and equipment requiring clean, stable air with electronic pressure verification.

AW20-02BCE2-D Specifications
