SMC AS2002F04 (AS2002F-04) - Speed Controller, Tube 4 mm x 4 mm, In-line Speed Controller

SMC AS2002F04 Speed Controller — In-line type with One-touch fittings both ends, 4 mm tube, meter-out. AS*002F series in-line type speed controller with One-touch fittings on both ends, applicable tube O.D. 4 mm. Meter-out control. Max operating pressure 1.0 MPa, operating temperature -5 to 60 C, PBT body. Mounts directly in the airline; compact, reduced mounting height.

MPN: AS2002F-04 · SKU: AS2002F04

AS2002F-04 Applications

The AS2002F-04 is an in-line speed controller with One-touch fittings on both ends from SMC's AS series, installed directly into a 4 mm air line to control actuator speed by metering out exhaust air. Its in-line body eliminates threaded ports and reduces mounting height, allowing a more compact machine design where the controller floats in the tubing between valve and cylinder. Ideal for retrofit and space-limited applications on small pneumatic actuators, it delivers smooth, repeatable speed control with quick One-touch tube connection.

AS2002F-04 Specifications
