SMC AR25N02NZ (AR25-N02-NZ) - Modular Regulator, NPT1/4 Port, Non-Relieving Type

SMC AR25N02NZ Modular Regulator — NPT1/4 port, non-relieving exhaust, psi scale. SMC AR25 modular regulator, body size 25, NPT1/4 (N02) inlet/outlet ports, 1/8 gauge port, non-relieving exhaust mechanism, psi nameplate/gauge. Set pressure range 0.05 to 0.85 MPa, max operating pressure 1.0 MPa, proof pressure 1.5 MPa, air fluid, -5 to 60 C, downward knob. Weight approx. 0.21 kg.

MPN: AR25-N02-NZ · SKU: AR25N02NZ

AR25-N02-NZ Applications

The AR25-N02-NZ is a modular air regulator with NPT1/4 ports and a non-relieving exhaust mechanism, so downstream pressure is not vented to atmosphere when the setting is reduced. It reads in psi for imperial-unit installations. Suited to sealed or process-critical air circuits where relief venting is undesirable, and connects modularly with SMC air preparation equipment for machine and line builds.

AR25-N02-NZ Specifications
