SMC AR20N02BGZB (AR20-N02BG-Z-B) - Regulator, 1/4 NPT port

SMC AR20N02BGZB Regulator — Modular F.R.L. regulator with round gauge, bracket and backflow option. Modular type regulator, body size 20; 1/4 NPT (N02) ports; round pressure gauge with limit indicator plus bracket (BG); Z option; backflow function option (-B series); set pressure range 0.05 to 0.7 MPa; relieving type; downward knob; left-to-right flow.

MPN: AR20-N02BG-Z-B · SKU: AR20N02BGZB

AR20-N02BG-Z-B Applications

The AR20-N02BG-Z-B is a modular air pressure regulator with a 1/4 NPT port, a round pressure gauge with limit indicator, mounting bracket, and backflow function option. It delivers stable regulated pressure from 0.05 to 0.7 MPa with relieving action for responsive control. Part of SMC's modular AR-B air preparation series, it stacks with matching filters and lubricators for compact FRL assemblies in NPT-piped factory automation.

AR20-N02BG-Z-B Specifications
