SMC AR20KF02ED (AR20K-F02E-D) - Modular Regulator, G1/4 Port, Backflow Square Embedded Gauge

SMC AR20KF02ED Modular Regulator — G1/4 port, backflow function, square embedded gauge, AR-D new-design series. SMC AR20K modular regulator with backflow function, body size 20, G1/4 (F02) inlet/outlet ports, 1/8 gauge port, square embedded type pressure gauge with limit indicator, part of the AR20(K)-D to AR60(K)-D new-design series. Set pressure range 0.05 to 0.85 MPa, max operating pressure 1.0 MPa, proof pressure 1.5 MPa, air fluid, -5 to 60 C, relieving type, downward knob. Weight approx. 0.16 kg.

MPN: AR20K-F02E-D · SKU: AR20KF02ED

AR20K-F02E-D Applications

The AR20K-F02E-D is a modular regulator with backflow function on G1/4 ports, part of SMC's current AR-D design family. The backflow function releases diaphragm-chamber pressure when the supply is shut off, allowing quick downstream exhaust for safety and reset. The square embedded gauge with limit indicator shows outlet pressure clearly. Ideal for machine air preparation where residual downstream pressure must be relieved on shutoff.

AR20K-F02E-D Specifications
