SMC AFM20F02CA Mist Separator — Size 20, G1/4 port, 0.3 micron, float auto drain (N.C.). SMC AFM20-F02C-A modular-type mist separator, body size 20, with G1/4 ports and 0.3 micron filtration (99.9% removal). Removes oil mist and fine particulates from compressed air. Features a float-type auto drain (N.C.), polycarbonate bowl, and a modular design that connects with other SMC air preparation equipment. Rated flow up to approx. 200 L/min (ANR at 0.7 MPa), max operating pressure 1.0 MPa, proof pressure 1.5 MPa, temperature -5 to 60 C.
MPN: AFM20-F02C-A · SKU: AFM20F02CA
AFM20-F02C-A Applications
Oil mist and fine particulate removal; pre-filter ahead of micro mist separators or precision equipment.
AFM20-F02C-A Specifications
| Brand | SMC | Manufacturer Part No. | AFM20-F02C-A |
| Product Type | Mist Separator | Series | AFM |
| Body Size | 20 | Thread Type | G |
| Port Size | 1/4 | Nominal Filtration | 0.3 micron (99.9%) |
| Rated Flow | 200 L/min (ANR, 0.7 MPa) | Drain Type | Float auto drain (N.C.) |
| Bowl Material | Polycarbonate | Max Operating Pressure | 1.0 MPa |
| Proof Pressure | 1.5 MPa | Ambient/Fluid Temperature | -5 to 60 C |
AFM20-F02C-A Datasheet & Manual
