SMC AC60F10B (AC60-F10-B) - Modular F.R.L. Air Combination Unit, G1 Size 60

SMC AC60F10B Modular F.R.L. Air Combination Unit — Largest size 60 body with G1 ports, separate filter + regulator + lubricator, no gauge, no auto drain. SMC AC60-F10-B modular-type F.R.L. air preparation combination unit, body size 60 (largest in the AC-B range) with G1 ports. Comprises a separate air filter, regulator and lubricator assembled as a modular set, with relieving exhaust and left-to-right flow, standard manual drain cock (no auto drain) and no pressure gauge. Polycarbonate bowl with transparent bowl guard for 360 degree visibility. Set pressure 0.05 to 0.85 MPa, max operating pressure 1.0 MPa, proof pressure 1.5 MPa, ambient/fluid temperature -5 to 60 C. Drain capacity 45 cm3, oil capacity 135 cm3..

MPN: AC60-F10-B · SKU: AC60F10B

AC60-F10-B Applications

Main-line, high-flow air preparation for large pneumatic installations requiring G1 connection and lubricated air.

AC60-F10-B Specifications
